SA-YQ30 hydraulic puller
Maximum linepull (kN):30 Continuous linepull (kN):25 Maximum linespeed (km/h):5 Bullwheel bottom of groove diameter(mm) :Φ300 Bullwheel grooves number : 7 Maximum suitable steelrope diameter (mm): Φ13 Maximum through connector diameter (mm): Φ40 Engine power /speed (kW/rpm):31/2200 Dimensions (mm):3200×1600×2000 Weight (kg): 1500
Product Description
Essential parameter
Maximum linepull (kN):30
Continuous linepull (kN):25
Maximum linespeed (km/h):5
Bullwheel bottom of groove diameter(mm) :Φ300
Bullwheel grooves number : 7
Maximum suitable steelrope diameter (mm): Φ13
Maximum through connector diameter (mm): Φ40
Engine power /speed (kW/rpm):31/2200
Dimensions (mm):3200×1600×2000
Weight (kg): 1500
Feature :
1. Infinitely variable speed and line control ,the pull in the rope can be read on the line pull gauge .
2. The max pull for conductor –stringing operation can preset ,automatic overpull protection system .
3. Spring applied –hydraulic release brake acts automatically in case of hydraulic failure ensure to safety .
4. Attached reel winder with automatically level wind .load and unload conveniently .
main component :
1. Chinese famous diesel engine.
2. Main pump:SAUER –SUNDSTRAND pump .main motor : SAI techniques product .
3. Radiator:AKG
4. Hydraulic instrument:WIKA
5. Mating with model GSP950 drum (order number :07125A).
