Aluminous alloy and MC nylon sheave hoisting tackle
High quality aluminum alloy and MC nylon sheave hoisting tackle for overhead transmission line conductor stringing. Optional aluminum alloy sheave or MC nylon sheave, lightweight, wear-resistant. China factory, competitive price, fast delivery.
Product Description
Aluminous Alloy and MC Nylon Sheave Hoisting Tackle
Lightweight hoisting tackle for line construction and lifting applications. Features aluminum alloy side panels and MC nylon sheaves for reduced weight and durability. Mono-sheave blocks are open-type design.
| Order Number | Model | Sheaves | Rated Load (kN) | Outside Diameter × Width (mm) | Weight (kg) | Hoisting Point Type |
|---|---|---|---|---|---|---|
| 11101 | QH1GN-1K | 1 | 10 | Φ100×31 | 1.8 | G, H |
| 11102 | QHN1-2 | 2 | 10 | Φ80×27 | 1.8 | G, H |
| 11103 | QHN1-3 | 3 | 10 | Φ80×27 | 2.1 | G, H |
| 11111 | QHN2-1K | 1 | 20 | Φ120×35 | 2.2 | G, H, B |
| 11112 | QHN2-2 | 2 | 20 | Φ100×31 | 2.6 | G, H |
| 11113 | QHN2-3 | 3 | 20 | Φ100×31 | 3.7 | G, H |
| 11121 | QHN3-1 | 1 | 30 | Φ150×39 | 3.4 | G, H, B |
| 11122 | QHN3-2 | 2 | 30 | Φ120×35 | 4.5 | G, H |
| 11123 | QHN3-3 | 3 | 30 | Φ100×31 | 4.6 | G, H |
| 11131 | QHN5-1K | 1 | 50 | Φ166×40 | 5.2 | G, H, B |
| 11133 | QHN5-2 | 2 | 50 | Φ150×39 | 5.5 | G, H |
| 11134 | QHN5-3 | 3 | 50 | Φ120×35 | 5.1 | G, H |
| 11141 | QHN8-1K | 1 | 80 | Φ205×49 | 7.2 | G, H, B |
| 11142 | QHN8-2 | 2 | 80 | Φ166×40 | 8.3 | G, H |
| 11143 | QHN8-3 | 3 | 80 | Φ150×39 | 7.9 | G, H |
| 11151 | QHN10-1K | 1 | 100 | Φ246×60 | 11.4 | G, B |
| 11152 | QHN10-2 | 2 | 100 | Φ166×40 | 10.2 | H |
| 11153 | QHN10-3 | 3 | 100 | Φ150×39 | 11.7 | H |
| 11161 | QHN15-1K | 1 | 150 | Φ280×65 | 12.1 | B |
| 11162 | QHN15-2 | 2 | 150 | Φ205×49 | 12.8 | H |
| 11163 | QHN15-3 | 3 | 150 | Φ166×40 | 11.8 | H |
| 11164 | QHN15-4 | 4 | 150 | Φ150×39 | 13.9 | H |
