Uses: Used for OPGW laying out or replacing old wires with new ones.

The main technical parameters:

Pulley diameter range (mm): φ9~φ26

Climbing Angle (°): 31

Gasoline generator model: YK950/650W

Drive motor model: 100YYJ140-3 (140W)

Remote control Barrier-free straight-line distance (m): 300~500

Dimensions (mm): 447×488×763

Walking speed (m/min): 17

Horizontal traction N): 350

Weight (kg): 46.5
