Technical Data


Item number

09162A

09162B

09162

Model

JJCS-50 JJQS-50 JJCS-50

Engine

Model

Diesel Engine

Gasoline Engine

Diesel Engine

Power(KW) 9 9 9
Speed(rpm) 2000 3600 2000



Pull(KN)

 speed

force/

(M/MIN)

Slow

50/5 50/5 50/3.1,40/9.6

Moderate

25/9  14/14 25/9   14/14 45/7.1,17/22.3

Fast

8/22 8/22 33/11.3,10/35.6

Reverse

-/5  -/9 -/5  -/9 -/7.35

Drum bottom of groove diamete(MM)

Φ230 Φ230 Φ300
outline size (MM) 1000x670x600 1000x670x600 2230x1210x1135
Weight(KG) 300 300 700
