Model:SH1Z660MG
Place of Origin:Zhejiang,China (Mainland)
Brand Name:REACH
Stringing Travelers:Helicopter Stringing Travelers
Model:SH1Z660mg
Quantity of sheave:single
Inner diameter of sheave:560 mm
Width of sheave:100 mm
Working load:20 KN

Dimension of sheave:φ660×100mm
Groove of sheave:depth 50mm×R33mm

Length of pilot bar:300mm
Dimension:660×255×805mm

Weight:28 kg

Uses: used on helicopter for installing pilot lines.

Characters:

1. The block can be hanged on the insulator directly.

2. Guiding arm can be folded for convenient transportation.

3. Nylon block, light weight and wear resistant.

4. Distance of anti-twisting pulling hole is 230mm.
